| General Specification |
| Image Size |
Min 7"~ Max 65" (Proper resolution) |
| Optical Engine |
Color Sequential 1,
3M (MM200) engine R.G.B
(Red, Green,Blue) |
| Resolution |
640 x 480 (VGA) |
| Aspect Ratio |
4:3 |
| Illumination Source |
RGB LED |
| LED life |
20,000 hrs |
| Brightness (ANSI) |
10 - 12 ANSI lumens |
| Sequential Contrast Ratio |
200:1 typical, minimum 80:1 |
| Image size range |
8’’~50’’ |
| Data input port |
Composite AV/ mini USB/ SD card slot/ built-in 1GB memory |
| Product Dimension |
11.5 x 6 x 2.6 cm |
| Focus |
Manual |
| |
| Audio & Video |
| Audio |
Built-in Stereo Speakers |
| Speaker Power |
2 x 0.5 W |
| Support format |
JPEG/BMP (Photo) AVI/MOV/DivX/XviD/3GP/MP4 (Video) (Power point file & PDF professional can be saved as JPEG and play via MP200) |
| |
| Electrical Connections / Inputs |
| USB Port |
mini USB ( Data transfer from Computer ) |
| Other Ports |
AV Input & Stereo Audio Output (Stereo Earphone Jack) |
| Power Input |
Alkaline AA battery/ adapter 5V/2A DC |
| Battery Life |
Alkaline AA battery * 4 / up to 6 hours |
| |
| Certification/Reports & Working Environment |
| RoHS |
YES |
| EMI test |
YES |
| Safety mode |
This device will automatically turn off once working temperature exceeds 65℃ |
| OSD Language |
Japanese/ English/ Spanish / French / Traditional Chinese/Dutch/Italy/Hebrew |
| |
| Pack out |
| Pack out Accessories |
| AC Adaptor (Regional plug types available by request) Remote Control USB 2.0 Cable A/V Cable Tripod Soft leather like carry pouch (Black, drawstring) User Manual Driver CD |
| |
| Product schedule |
| Lead Time |
45~60 days (After PO is confirmed) |
| |
